Kohler 60ERESB

60 kW, Single Phase or 3 Phase, Natural Gas|LP

Reliable power for very large residential or small business needs. Built to weather the storms, hard-working 60/80/100 kW KOHLER® generators with industrial-grade engines keep your family comfortable and your business running when a utility failure or storm knocks out power.

Features

  • Powerful. In just 10 seconds, your KOHLER generator automatically powers everything, keeping you connected to the things you love to do.*

  • Smart. You get steady, high-quality power that protects sophisticated electronics from damage related to low-quality power sources.

  • Premium warranty. We’ve got you covered with 5-year, 2,000-hour protection.

  • Advanced. The Decision-Maker® 3000 controller with patented software is compatible with optional accessories that let you monitor your system remotely through your PC.

  • Exterior options. Choose the optional corrosion-resistant aluminum enclosure or standard steel enclosure.

THE POWER YOU NEED

  • A popular choice for industrial applications

  • Excellent peak motor-starting capacity: 60ERESB: 144kVA at 240V; 80ERESD: 237kVA at 240V; 100ERESD: 440kVA at 240V

  • Premium power quality delivers exceptional digital voltage and frequency regulation along with extremely low levels of harmonic distortion to protect sophisticated electronics

  • Powered by General Motors Vortec automotive-grade engine with hydraulic valve lifters to eliminate need for lengthy break-in periods and expensive valve adjustments; operation speed 1800 rpm

THE CONVENIENCES YOU EXPECT

  • Decision-Maker® 3000 controller provides advanced control, system monitoring and system diagnostics with remote-monitoring capability

  • Quiet, neighborhood-friendly operation with sound similar to a typical central air conditioner

  • Standard steel enclosure with automotive-grade paint

  • Optional corrosion-resistant aluminum enclosure

  • Runs on either natural gas or liquid propane (LPG) with simple switching between natural gas and LPG in the field

*Based on generator and load size.

Specifications

Rated kW LP 60 kW
Rated kW NG 60 kW
Amps LP 250 amps
Amps NG 250 amps
Peak Motor Starting kVA @240 V 144 kVa
Alternator Note All information shown is for 1 Phase 60 Hz generator with the largest alternator option available.
Displacement 5.7 L (350 cu. in.)
Horsepower 105 HP
Enclosure Material Steel|Aluminum
Sound Output During Full-speed Operation 64 dB(A)
Response Time 10 seconds
Warranty Five-year extended warranty
Country of Origin US
Certifications/Listings EPA|CSA
Automatic Transfer Switch Included No
Remote Monitoring Available Yes
Off Grid / Utility Backup Utility Backup
Weight 2283 lbs.
Alternator Type Brushless, Rare-Earth Permanent-Magnet
Fuel Consumption on NG at 50% load? 520 cfh
Fuel Consumption on LP at 50% load? 520 cfh
Controller Decision-Maker® 3000
Cylinder Arrangement V-8
Dimensions 2585mm x 1078mm x 1513mm (102 in. x 42.4 in. x 59.6 in.)
Engine Manufacturer/Description General Motors
Engine Model Industrial Powertrain Vortec 5.7L
Engine/Alternator RPM 1800
Fuel Type Natural Gas|LP
Frequency 60 Hz|50 Hz
Phase Single Phase or 3 Phase
Voltage @ 60 Hz 120/240
Digital Voltage Regulation ±0.5%
